Tokheim Diesel Pump Filter Element
Tokheim Diesel Pump Filter Element

Tokheim Diesel Pump Filter Element

The use of high-precision filtration materials, can effectively filter small impurities in the fuel, such as rust, dust, sludge and so on.

Products Description

Features:

High filtration accuracy: The use of high-precision filtration materials, can effectively filter small impurities in the fuel, such as rust, dust, sludge and so on.

It has a unique three-layer structure design: the first layer is a coarse filter impurity structure, the second layer is a filter water structure, and the third layer is a fine filter impurity structure, which can filter the oil products with high precision and filter the water in it.

Suitable for a wide range of oil products: respectively suitable for gasoline, ethanol gasoline, diesel.

With strong water absorption function: when the trace water in the oil passes through the filter element, the demulsifier can quickly break the emulsified water into oil and free water, and the unique water absorption filter material instantly absorbs free water, effectively preventing water from passing through the refueling machine. When a large amount of water in the oil passes through the filter element and exceeds its absorption capacity, the water absorption filter material will react quickly to reduce the filter aperture until it is completely closed to cut off the oil circuit and prevent the passage of water. Water filter material has super water retention ability, under the high pressure of the refueling machine, the water absorbed by the filter element will not be rushed out.

Care and maintenance

Regular inspection: It is recommended to check the working status of the filter element regularly to observe whether there is blockage, deformation or damage to ensure the normal operation of the filter element.

Timely replacement: According to the use and filtration effect, when it is found that the filter filter efficiency is significantly reduced, such as the oil output speed of the tanker, the engine is abnormal, etc., the filter should be replaced in time.

Correct installation: When replacing the filter element, be sure to follow the correct installation method to ensure that the filter element is firmly installed and the connection thread is well sealed to avoid problems such as fuel leakage or poor filtering effect caused by improper installation.
Sinoart enterprise content manager system | Sinoart CMS
Technical Index
 Model    Filter Element
Applicable model Commercial Refueling Machine
Micron Rating 10/30/60 Micron (nominal)
Diameter 85mm
Height 100mm
