Washable Fuel Filter for Fill Station
Washable Fuel Filter for Fill Station

Washable Fuel Filter for Fill Station

Fuel Type: Straight Gasoline, Ethanol and methanol Blends up to 10%,Diesel/ULSD

Function: Remove Particulate

Thread: 1 1/2"-16UNF

Petroleum Micron: 30

Filter Size: 3.75" x 5.31"

Media: CELLULOSE
Send Email Inquiry Now
Specifications
1. High filtration accuracy: The use of advanced filtration materials and processes, can effectively remove small particles of impurities in the fuel, such as rust, sand, dust, etc., the filtration accuracy is usually up to 30-60μm, to ensure the cleanliness of the fuel.

2. Reasonable structure design: the overall structure is compact, easy to install, and the internal flow path design is scientific, which can ensure the smooth passage of fuel, reduce pressure loss, and facilitate maintenance and replacement of filter elements.

3. Good durability: the shell is made of high quality metal materials, has good pressure resistance and corrosion resistance, can adapt to a variety of harsh working environment, the filter is made of high quality filter materials, long service life.

The Reusable Filter

The Reusable filter are designed for enlarge the filter working life and substitute the disposable filter, in order to save customer’s cost and protect the environment.

Reusable filter are only need to unload and clean the filter cartridge and then install back for use, in order to meet the markets request, we development the paper material cartridge, stainless steel mesh material and water absorb cartridge for substitutes.



Technical Parameter
Model R18189-30U
Filter Type The Reusable Filter
Media Type Cellulose
Micron Rating 30- Micron (nominal)
Diameter 97mm
Height 135mm
Flow Rate 25 gpm (94.6 lpm)
Shell Thickness 0.05
Gasket Material Buna N
Collapse (Min.) 150 psid (10.3 bar)
Burst (Min.) 250 psi (17.2 bar)
Max. Operating Temp. 250°F (139°C)
